te5-369 慢断 塑壳方块形保险丝
产品信息
产品类别：塑壳微型保险丝
关键词：te5-369,慢断,塑壳方块形保险丝
点击率：
发布时间：2019-01-26 16:48:21
全国服务热线：13549460265
产品详情
description
te5®, time-lag type, 300v rated, designed in accordance to iec 60127-3.
features
• lead-free • reduced pcb space requirements • direct solderable or plug-in versions • internationally approved
• low internal resistance • shock safe casing • vibration resistant • halogen free
applications
• battery charges • consumer electronics • power supplies • industrial controllers
|
% of ampere rating |
opening time |
|
150% |
1 hour, min. |
|
210% |
120 s, max. |
|
275% |
400 ms min. ; 10 sec. max. |
|
400% |
150 ms min. ; 3 sec. max. |
|
1000% |
20 ms min. ; 150 ms max. |
electrical characteristic specifications by item
|
rated current |
amp code |
voltage rating |
breaking capacity |
voltage drop 1.0×in max. (mv) |
power dissipation 1.5×in max. (mw) |
meltingintegral 10×inmin. (a2s) |
agency approvals |
|||||
|
vde |
s |
ur |
pse |
cqc |
kc |
|||||||
|
50ma |
005 |
300v |
50a/300 vac
|
1350 |
85 |
0.003050 |
x |
x |
x |
x |
x |
|
|
63ma |
0063 |
300v |
1200 |
85 |
0.00820 |
x |
x |
x |
x |
x |
|
|
|
100ma |
0100 |
300v |
1350 |
100 |
0.06500 |
x |
x |
x |
x |
x |
|
|
|
125ma |
0125 |
300v |
1100 |
110 |
0.1000 |
x |
x |
x |
x |
x |
|
|
|
160ma |
0160 |
300v |
1000 |
160 |
0.2005 |
x |
x |
x |
x |
x |
x |
|
|
200ma |
0200 |
300v |
950 |
185 |
0.443 |
x |
x |
x |
x |
x |
x |
|
|
250ma |
0250 |
300v |
900 |
200 |
0.735 |
x |
x |
x |
x |
x |
x |
|
|
315ma |
0315 |
300v |
600 |
215 |
1.00 |
x |
x |
x |
x |
x |
x |
|
|
500ma |
0500 |
300v |
400 |
235 |
1.55 |
x |
x |
x |
x |
x |
x |
|
|
630ma |
0630 |
300v |
200 |
255 |
2.63 |
x |
x |
x |
x |
x |
x |
|
|
800ma |
0800 |
300v |
110 |
280 |
3.80 |
x |
x |
x |
x |
x |
|
|
|
1.00a |
1100 |
300v |
115 |
400 |
5.80 |
x |
x |
x |
x |
x |
x |
|
|
1.2 |
1125 |
300v |
100 |
500 |
9.75 |
x |
x |
x |
x |
x |
x |
|
|
1.60a |
1160 |
300v |
95 |
600 |
13.50 |
x |
x |
x |
x |
x |
x |
|
|
2.00a |
1200 |
300v |
90 |
700 |
21.00 |
x |
x |
x |
x |
x |
x |
|
|
2.50a |
1250 |
300v |
85 |
750 |
32.00 |
x |
x |
x |
x |
x |
x |
|
|
3.1 |
1315 |
300v |
80 |
1100 |
55.00 |
x |
x |
x |
x |
x |
x |
|
|
4.00a |
1400 |
300v |
75 |
1200 |
100.00 |
x |
x |
x |
x |
x |
x |
|
|
5.00a |
1500 |
300v |
70 |
1000 |
90.00 |
x |
x |
x |
x |
x |
x |
|
|
6.30a |
1630 |
300v |
65 |
1200 |
126.00 |
x |
x |
x |
x |
x |
|
|
note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
temperature derating curve
average time current curves
product characteristics
|
materials |
base/cap: brown thermoplastic polyamide pa 6.6, ul 94 v-0 round pins: copper, tin-plated |
|
lead pull strength |
10 n (iec 60068-2-21) |
|
solderability |
260ºc, ≤ 3 sec. (wave) 350ºc, ≤ 3 sec. (soldering iron) |
|
soldering heat resistance |
260ºc, 10 sec. (iec 60068-2-20) 350ºc, ≤ 3 sec. (soldering iron) |
|
operating temperature |
–40ºc to 85ºc (consider de-rating)
|
|
climatic category |
–40ºc to 85ºc/21 days (en 60068-1, -2-1, -2-2, -2-78) |
|
stock condition |
10 ºc to 60 ºc relative humidity ≤ 75% yearly average, without dew, maximum value for 30 days - 95% |
|
vibration resistance |
24 cycles at 15 min. each(en 60068-2-6)10–60 hz at 0.75 mm amplitude 60–2000 hz at 10 g acceleration |
dimensions
packaging
|
packaging option |
packaging specification |
quantity |
|
12mm tape and reel |
n/a |
1400 |
