1812贴片压敏电阻 -手机赌钱官网app下载安卓

 model number

working
voltage
(max)

breakdown
voltage

peak
current
(max)

clamping
voltage
(max)

energy
absorption
(max)

typical
capacitance

unit condition

ac
(vrms)

dc
(v)

1ma
(v)

8/20us
(a)

(a)

(v)

10/1000
(j)

1khz
(pf)

1812ml150k

8

11

15

800

5

25

1.8

9300

1812ml180k

11

14

18

800

5

30

1.9

8500

1812ml220k

12

16.5

22

800

5

36

2.3

6200

1812ml270k

17

22

27

800

5

44

2.7

4800

1812ml330k

20

26

33

800

5

54

3.0

3800

1812ml390k

25

30

39

800

5

65

3.7

3400

1812ml470k

30

38

47

800

5

77

4.2

2900

1812ml560k

35

45

56

800

5

90

4.2

2400

 notes:
 1.tolerance of breakdown voltage:15~18=±15%,22~56v=±15% 。
 2.tolerance of capacitance voltage:±20% 。
 3.typical leakage at 25℃<50ua, maximum leakage 100ua 。
 4.in order to satisfy the applications of customer in various fields, the capacitance range
 ※can be designed during manufacturing according
  to the request, please contact our sales department if needed 。
