6*30引线式防水保险丝座hfb

dimensions -  (mm)

note: l1 and l2 are customized according to customer requirements.

description

product features

• for 6.35 mm x 31.8 mm  fuses

• ip67 rating for exposed locations，injection molding of electronic wire

• ideal for harsh environments

o water, salt spray

o ultraviolet light, ozone

o -40 °c to 150 °c temperature range

o withstands many organic solvents and

rigorous shock and vibration

• standard hfb accepts #16 to #12 awg cu wire

• hfb-10 accepts #10 awg cu wire

• ul flammability rating 94 v0

general specifications

• temperature rating (rti): 100 °c

• ip67 rating for exposed locations，injection molding of electronic wire

• vibration resistance: per mil std 810c

• humidity: 85 °c/85% relative humidity for 96 hours

• brittle point: less than -60 °c

• abrasion: 54% nbs index

• fluid resistance: type and class aa, ba, bc, be, ca, ce

per astm d-2000 standard classification system for

rubbers

• flame resistance: pass fmvss302 and related slow

burning when tested in accordance with ul 94v0

• ozone resistance: passed 70 hours in 50 ppm ozone per

astm d-5

• salt spray: 15% for 166 hours = 0% volume swell
