0603贴片自恢复保险丝
产品信息
产品类别：贴片自恢复保险丝
关键词：0603贴片自恢复保险丝
点击率：
发布时间：2019-08-10 14:48:52
全国服务热线：13549460265
产品详情
performance specification
|
model |
marking |
|
|
|
|
|
maximum |
resistance |
认证 |
||
|
v max |
imax |
i hold |
i trip |
pd |
time to trip |
||||||
|
|
|
@25°c |
@25°c |
typ. |
current |
time |
r i min |
r1max |
ul |
||
|
(v dc) |
(a) |
(a) |
(a) |
(w) |
(a) |
(sec) |
(w) |
(w) |
|||
|
smd0603r001sf |
x |
60 |
20 |
0.01 |
0.03 |
0.5 |
0.2 |
1.00 |
15.000 |
100.000 |
|
|
smd0603r002sf |
y |
60 |
20 |
0.02 |
0.06 |
0.5 |
0.2 |
1.00 |
12.000 |
70.000 |
|
|
smd0603r002sf9v |
y |
9 |
20 |
0.02 |
0.06 |
0.5 |
0.2 |
1.00 |
12.000 |
70.000 |
√ |
|
smd0603r003sf |
z |
30 |
20 |
0.03 |
0.09 |
0.5 |
0.2 |
1.00 |
6.000 |
50.000 |
|
|
smd0603r003sf9v |
z |
9 |
20 |
0.03 |
0.09 |
0.5 |
0.2 |
1.00 |
6.000 |
50.000 |
√ |
|
smd0603r004sf |
- |
24.0 |
20 |
0.04 |
0.12 |
0.5 |
0.20 |
1.00 |
4.000 |
40.000 |
|
|
smd0603r005sf |
- |
15.0 |
20 |
0.05 |
0.15 |
0.5 |
0.25 |
1.00 |
3.800 |
30.000 |
|
|
smd0603r005sf9v |
- |
9.0 |
20 |
0.05 |
0.15 |
0.5 |
0.25 |
1.00 |
3.800 |
30.000 |
√ |
|
smd0603r010sf |
1 |
15.0 |
35 |
0.10 |
0.30 |
0.5 |
0.5 |
1.00 |
0.900 |
6.000 |
|
|
smd0603r010sf9v |
1 |
9.0 |
35 |
0.10 |
0.30 |
0.5 |
0.5 |
1.00 |
0.900 |
6.000 |
√ |
|
smd0603r020sf |
2 |
9.0 |
35 |
0.20 |
0.50 |
0.5 |
1.0 |
0.60 |
0.550 |
3.500 |
√ |
|
smd0603r020sf16v |
2 |
16.0 |
35 |
0.20 |
0.50 |
0.5 |
1.0 |
0.60 |
0.550 |
3.500 |
|
|
smd0603r025sf |
2 |
9.0 |
35 |
0.25 |
0.55 |
0.5 |
8.0 |
0.08 |
0.500 |
3.000 |
√ |
|
smd0603r025sf16v |
2 |
16.0 |
35 |
0.25 |
0.55 |
0.5 |
8.0 |
0.08 |
0.500 |
3.000 |
|
|
smd0603r035sf |
3 |
6.0 |
35 |
0.35 |
0.75 |
0.5 |
8.0 |
0.10 |
0.200 |
1.000 |
|
|
smd0603r040sf |
5 |
6.0 |
35 |
0.40 |
0.80 |
0.5 |
8.0 |
0.10 |
0.150 |
0.900 |
|
|
smd0603r050sf |
5 |
6.0 |
35 |
0.50 |
1.00 |
0.5 |
8.0 |
0.10 |
0.100 |
0.800 |
|
|
smd0603r050sf12v |
5 |
12.0 |
35 |
0.50 |
1.00 |
0.5 |
8.0 |
0.10 |
0.100 |
0.800 |
|
|
smd0603r060sf |
7 |
6.0 |
35 |
0.60 |
1.20 |
0.5 |
8.0 |
0.10 |
0.080 |
0.600 |
|
|
smd0603r065sf |
7 |
6.0 |
35 |
0.65 |
1.30 |
0.5 |
8.0 |
0.10 |
0.070 |
0.550 |
|
|
smd0603r075sf |
7 |
6.0 |
35 |
0.75 |
1.40 |
0.5 |
8.0 |
0.10 |
0.060 |
0.450 |
|
|
smd0603r100sf |
0 |
6.0 |
35 |
1.00 |
2.00 |
0.5 |
8.0 |
0.10 |
0.050 |
0.300 |
|
v max = maximum operating voltage device can withstand without damage at rated current (imax).
i max = maximum fault current device can withstand without damage at rated voltage (v max).
i hold = hold current. maximum current device will not trip in 25°c still air.
i trip = trip current. minimum current at which the device will always trip in 25°c still air.
pd = power dissipation when device is in the tripped state in 25°c still air environment at rated voltage.
ri min/max = minimum/maximum device resistance prior to tripping at 25°c.
r1max = maximum device resistance is measured one hour post reflow.
caution : operation beyond the specified ratings may result in damage and possible arcing and flame.
environmental specifications
|
test |
|
|
|
conditions |
|
|
|
resistance change |
|
|
|
passive aging |
|
|
|
85°c, 1000 hrs. |
|
|
±5% typical |
|
|
|
|
humidity aging |
|
|
|
85°c, 85% r.h. , 168 hours |
|
±5% typical |
|
|
||
|
thermal shock |
|
|
|
85°c to -40°c, 20 times |
|
|
±33% typical |
|
||
|
resistance to solvent |
|
|
|
mil-std-202,method 215 |
|
|
no change |
|
|
|
|
vibration |
|
|
|
mil-std-202,method 201 |
|
|
no change |
|
|
|
|
ambient operating conditions : - 40 °c to 85 °c |
||||||||||
|
maximum surface temperature of the device in the tripped state is 125 °c |
||||||||||
thermal derading chart
recommended hold current(a) at ambient temperature(°c)
|
model |
ambient operation temperature |
||||||||
|
-40°c |
-20°c |
0°c |
25°c |
40°c |
50°c |
60°c |
70°c |
85°c |
|
|
smd0603r001sf |
0.016 |
0.014 |
0.012 |
0.010 |
0.008 |
0.007 |
0.006 |
0.005 |
0.0035 |
|
smd0603r002sf |
0.031 |
0.027 |
0.024 |
0.020 |
0.016 |
0.014 |
0.012 |
0.011 |
0.007 |
|
smd0603r003sf |
0.047 |
0.041 |
0.036 |
0.030 |
0.024 |
0.021 |
0.018 |
0.016 |
0.0108 |
|
smd0603r004sf |
0.052 |
0.048 |
0.044 |
0.040 |
0.032 |
0.028 |
0.024 |
0.020 |
0.012 |
|
smd0603r005sf |
0.065 |
0.060 |
0.055 |
0.050 |
0.040 |
0.035 |
0.031 |
0.025 |
0.015 |
|
smd0603r010sf |
0.13 |
0.12 |
0.11 |
0.10 |
0.08 |
0.07 |
0.06 |
0.05 |
0.03 |
|
smd0603r020sf |
0.27 |
0.25 |
0.23 |
0.20 |
0.17 |
0.14 |
0.12 |
0.10 |
0.07 |
|
smd0603r025sf |
0.32 |
0.29 |
0.27 |
0.25 |
0.21 |
0.18 |
0.16 |
0.14 |
0.10 |
|
smd0603r035sf |
0.47 |
0.41 |
0.38 |
0.35 |
0.29 |
0.26 |
0.24 |
0.20 |
0.14 |
|
smd0603r040sf |
0.54 |
0.47 |
0.43 |
0.40 |
0.33 |
0.29 |
0.27 |
0.22 |
0.16 |
|
smd0603r050sf |
0.67 |
0.59 |
0.54 |
0.50 |
0.41 |
0.37 |
0.34 |
0.29 |
0.20 |
|
smd0603r060sf |
0.81 |
0.70 |
0.651 |
0.60 |
0.49 |
0.44 |
0.41 |
0.34 |
0.24 |
|
smd0603r065sf |
0.87 |
0.76 |
0.71 |
0.65 |
0.54 |
0.48 |
0.44 |
0.37 |
0.26 |
|
smd0603r075sf |
0.98 |
0.85 |
0.81 |
0.75 |
0.60 |
0.54 |
0.44 |
0.40 |
0.31 |
|
smd0603r100sf |
1.19 |
1.13 |
1.08 |
1.00 |
0.80 |
0.72 |
0.59 |
0.54 |
0.43 |
thermal derating curve average time-current curve
soldering parameters
|
profile feature |
pb-free assembly |
|
average ramp-up rate(ts max to t p) |
3℃/second mac. |
|
preheat -temperature min(ts min) -temperature max(ts max) -time(ts min to ts max) |
150℃ 200℃ 60~180 seconds |
|
time maintained above: -temperature(tl) -time(tl) |
217℃ 60~150 seconds |
|
peak temperature(tp) |
260℃ |
|
ramp-down rate |
6℃/second max. |
|
time 25℃ to peak temperature |
8 minutes max |
|
storage condition |
0℃~35℃,30%-60%rh |
recommended reflow methods: ir, vapor phase oven, hot air oven, n2 environment for lead-free
recommended maximum paste thickness is 0.25mm
devices can be cleaned using standard industry methods and solvents.
note 1:all temperature refer to topside of the package, measured on the package body surface.
note 2: if reflow temperatures exceed the recommended profile, devices may not meet the performance requirements
physical dimensions(mm.)
|
型號 |
a |
b |
c |
d |
e |
|||
|
min. |
max. |
min. |
max. |
min. |
max. |
min. |
min. |
|
|
smd0603r001sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r002sf9v |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r002sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r003sf9v |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r003sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r004sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r005sf9v |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r005sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r010sf9v |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r010sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r020sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r020sf16v |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r025sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r025sf16v |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
1.00 |
0.15 |
0.10 |
|
smd0603r035sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.35 |
0.90 |
0.15 |
0.10 |
|
smd0603r040sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.40 |
0.90 |
0.15 |
0.10 |
|
smd0603r050sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.55 |
1.15 |
0.15 |
0.10 |
|
smd0603r050sf12v |
1.45 |
1.85 |
0.65 |
1.05 |
0.55 |
1.15 |
0.15 |
0.10 |
|
smd0603r060sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.55 |
1.15 |
0.15 |
0.10 |
|
smd0603r065sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.55 |
1.15 |
0.15 |
0.10 |
|
smd0603r075sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.55 |
1.15 |
0.15 |
0.10 |
|
smd0603r100sf |
1.45 |
1.85 |
0.65 |
1.05 |
0.55 |
1.15 |
0.15 |
0.10 |
termination pad characteristics
terminal pad materials：tin-plated nickel-copper
terminal pad solder ability：meets eia specification rs186-9e and ansi/j-std-002 category 3.
recommended pad layout (mm.)
packaging quantity
|
part number |
quantity |
|
smd0603 hf series |
4,000 pcs/reel |
tape & reel packaging per eia481-1
tape and reel specifications (mm)
|
governing specifications |
eia 481-1 |
|
|
w |
|
8.0 ± 0.2 |
|
p0 |
|
4.0 ± 0.10 |
|
p1 |
|
4.0 ± 0.10 |
|
p2 |
|
2.0 ± 0.05 |
|
a0 |
|
1.05 ± 0.10 |
|
b0 |
|
1.85 ± 0.10 |
|
d0 |
|
1.55 0.05 |
|
f |
|
3.5 ± 0.05 |
|
e1 |
|
1.75 ± 0.10 |
|
e2min. |
|
6.25 |
|
t |
|
0.20 |
|
t1max. |
|
0.1 |
|
k0 |
|
0.75/0.95 ± 0.1 |
|
leader min. |
|
390 |
|
trailer min. |
|
160 |
|
卷軸規格 |
|
|
|
a max. |
|
178 |
|
n min. |
|
60 |
|
w1 |
|
9.0 ± 0.5 |
|
w2 |
|
12.0 ± 0.05 |
|
w |
|
8.0 ± 0.2 |
|
|
|
|
|
storage and handling |
||
|
‧ storage conditions：35°c max, 30%-60% r.h. |
||
|
‧devices may not meet specified performance |
||
|
if storage conditions are exceeded. |
||
