max-大号汽车插片保险丝-20a-120a/32v-125v
产品信息
产品类别：车用保险丝|直流保险丝
关键词：max-大号汽车插片保险丝
点击率：
发布时间：2019-07-02 09:54:11
全国服务热线：13549460265
产品详情
| 大号汽车插片保险丝---mxa ul csa |
|
|
physical view
voltage rating: 125 vdc
interrupting ratings: 1000a @ 125 vdc
operating temperature range: -40ⅹc to 125ⅹc
terminals: ag plated zinc alloy/sn plated zinc alloy
housing material: pa66/pc
complies with: sae j 1888
iso 8820-3:2002(e)
time-current characteristics
ratings
voltage rating: 125 vdc
interrupting ratings: 1000a @ 125 vdc
operating temperature range: -40ⅹc to 125ⅹc
terminals: ag plated zinc alloy/sn plated zinc alloy
housing material: pa66/pc
complies with: sae j 1888
iso 8820-3:2002(e)
time-current characteristics
| % of rating | opening time | |
| mini | max | |
| 110 | 4h | / |
| 135 | 60s | 1800s |
| 200 | 2 s | 60 s |
| 350 | 0.20s | 7s |
| 600 | 0.040s | 1s |
| type | rating current(a) | rating voltage(v) | typ. voltage drop(mv) |
cold resistance （mω） |
i2t | color |
| fymax-20 | 20a | 32v/48v/63v/80v/125v | 76 | 3.10 | 1100 | yellow |
| fymax-25 | 2 | 32v/48v/63v/80v/125v | 75 | 2.39 | 2087 | grey |
| fymax-30 | 30a | 32v/48v/63v/80v/125v | 77 | 1.95 | 4070 | green |
| fymax-40 | 40a | 32v/48v/63v/80v/125v | 75 | 1.71 | 6032 | amber |
| fymax-50 | 50a | 32v/48v/63v/80v/125v | 75 | 1.42 | 8450 | red |
| fymax-60 | 60a | 32v/48v/63v/80v/125v | 73 | 1.10 | 11300 | blue |
| fymax-70 | 70a | 32v/48v/63v/80v/125v | 77 | 0.89 | 15300 | brown |
| fymax-80 | 80a | 32v/48v/63v/80v/125v | 61 | 0.64 | 6900 | white |
| fymax-100 | 100a | 32v/48v/63v/80v/125v | 52 | 0.45 | 9600 | brown |
time-current characteristic curves
|
temperature rerating curve
|
