mega-中号汽车叉栓保险丝
产品信息
产品类别：车用保险丝|直流保险丝
关键词：mega-中号汽车叉栓保险
点击率：
发布时间：2019-08-16 18:28:14
全国服务热线：13549460265
产品详情
physical view
dimensions (mm)
specifications
interrupting rating: 2000a @ 32 vdc
voltage rating: 32 v/48v/63v/125vdc
operating temperature range: -40˚c to 125˚c
housing material: ppa-gf33hs
clear top housing material: pes (top) ppa-gf33hs (bottom)
terminals: copper (silver plated copper available)
m6 or m8 bolts available
mounting torque: 8-14 nm m6, 12-18 nm m8
complies with: iso 8820-5
time-current characteristics
|
% of rating |
opening time min / max (s) |
|
|
100a - 250a |
300a-500a |
|
|
75 |
– / – |
– / – |
|
100 |
4 h / – |
4 h / – |
|
135 |
120 s / 1,800 s |
– / – |
|
200 |
1 s / 15 s |
1 s / 15 s |
|
350 |
0.300 s / 5 s |
0.500 s / 5 s |
|
600 |
0.100 s / 1 s |
0.100 s / 1 s |
ratings
|
type |
current rating (a)
|
voltage drop (mv)
|
cold resistance (mω)
|
i 2 t (a 2 s)
|
|
fymega-40 |
40 |
132 |
2.510 |
8700 |
|
fymega-60 |
60 |
119 |
1.504 |
21000 |
|
fymega-80 |
80 |
87 |
0.720 |
21500 |
|
fymega-100 |
100 |
87 |
0.562 |
31100 |
|
fymega-125 |
125 |
80 |
0.423 |
57800 |
|
fymega-150 |
150 |
92 |
0.352 |
100000 |
|
fymega-175 |
175 |
86 |
0.294 |
168000 |
|
fymega-200 |
200 |
83 |
0.257 |
204000 |
|
fymega-225 |
225 |
82 |
0.222 |
257000 |
|
fymega-250 |
250 |
82 |
0.201 |
389000 |
|
fymega-300 |
300 |
74 |
0.167 |
315000 |
|
fymega-350 |
350 |
68 |
0.138 |
500000 |
|
fymega-400 |
400 |
64 |
0.126 |
610000 |
|
fymega-450 |
450 |
60 |
0.112 |
1050000 |
|
fymega-500 |
500 |
58 |
0.092 |
2050000 |
temperature rerating curve
time-current characteristic curves
