physical view

dimensions (mm)

specifications
interrupting rating: 1000a @ 80 vdc
voltage rating: 32-80 vdc
operating temperature range: -40˚c to  125˚c
terminals: ag plated zinc alloy/sn plated zinc alloy
housing materials: pa66/pc
complies with: meets sae j2077
 iso 8820
 ul 248 special purpose fuses

time-current characteristics

% of rating	opening time nennstrom	opening time min / max (s)
100	35~40	360,000 s / –
110	1~30	360,000 s / –
135	1~2 3~40	500ms~600ms 0.75 s / 600 s
200	1~2 3~40	100ms~5s 0.15 s / 5 s
350	1~40	0.080 s / 500ms
600	1~40	100ms / 150ms

ratings

prt number	rating current(a)	rating voltage(v)	typ. voltage drop (mv)	coldresistance kaltwiderstand (mω)	i2t	color
fyatc-01	1a	32v/48v/63v/80v	176	123	0.4	blue ash
fyatc-02	2a	32v/48v/63v/80v	141	53.5	1.4	celandine
fyatc-03	3a	32v/48v/63v/80v	137	31.1	7.4	purple
fyatc-04	4a	32v/48v/63v/80v	136	22.8	14	pink
fyatc-05		32v/48v/63v/80v	128	17.85	26	orange
fyatc-075	7.	32v/48v/63v/80v	116	10.91	60	tan
fyatc-10	10a	32v/48v/63v/80v	109	7.70	115	red
fyatc-15	1	32v/48v/63v/80v	102	4.80	340	blue
fyatc-20	20a	32v/48v/63v/80v	98	3.38	520	yellow
fyatc-25	25	32v/48v/63v/80v	92	2.52	1080	natural
fyatc-30	30a	32v/48v/63v/80v	84	1.97	1510	green
fyatc-35	3	32v/48v/63v/80v	87	1.61	2280	purp red
fyatc-40	40a	32v/48v/63v/80v	96	1.44	3310	dark red



time-current characteristic curves

temperature rerating curve
