physical view





尺寸未标示公差：五金部分±0.3mm，塑胶部分：±0.5mm

description
the micro2 ™ fuse is the new standard for vehicle circuit protection. its sub-miniature design meets the need for more circuits to be protected while utilizing less space and its ability to cope with high temperatures in adverse environments makes the micro2 ™  fuse of recommended choice for protection.
‧根据使用状况，保险丝特性可能改变
according to the using status, the fuse characteristics may change.
‧额定电压：小于直流32v/48v ‧
rated voltage: dc  less than 32v,
‧分断容量：1000a@358v dc ‧使用温度：-40℃～ 125℃
breaking capacity: 1000a@32v, dc, temperature: -40 ℃ ~ 125 ℃
‧材质：1、锌合金；2、尼龙料pa66/pc
material: 1、ag plated zinc alloy , 2、 pa66 plastic/pc.



time-current characteristics

% of rating	opening time min / max (s)
110	100 h / –
135	0.75 sec / 120 sec
160	0.30 sec / 50 sec
200	0.15 sec / 5 sec
350	0.04 sec / 0.50 sec
600	0.02 sec / 0.100 sec


ratings

prt number	rating current(a)	rating voltage(v)	typ. voltage drop(mv)	cold resistance (mω)	i2t	color
327005		32v	116	17.4	17	orange
327075	7.	32v	106	10.8	47	tan
327010	10a	32vv	102	7.7	89	red
327015	1	32v	94	4.9	189	blue
327020	20a	32v	91	3.5	397	yellow
327025	2	32v	90	2.6	585	natural
327030	30a	32v	88	2.1	1028	green


time-current characteristic curves



temperature rerating curve
